Mar 2, 2011

Missing Documentation: tex2Dlod()

Today, I tried to use tex2Dlod() to generate the full mip chain of a texture. HLSL function, tex2Dlod() takes float4 as texture coordinate and the 4th component is supposed to specify which mip level it should sample.

So my question was "what value should I pass if i want the 2nd highest mip." I had two educated guesses:

  1. texcoord = float4(u, v, 0, 1);


  2. texccord = float4(u, v, 0, 1 / number of total mip levels)

Unfortunately, I was not able to find any documentation on this: MSDN doesn't explain it and I couldn't find it on Google either.  (my Google God status is being challenged here. :-) OMG! )

My co-worker Doctor Barrero did a quick test on Render Monkey, and the answer is 1. (the first choice, or passing simply 1 as the 4th component).  Also you can deduce the same answer from D3D Sampler State, D3DSAMP_MAXMIPLEVEL, which is documented as:
D3DSAMP_MAXMIPLEVEL: level-of-detail index of largest map to use. Values range from 0 to (n - 1) where 0 is the largest. The default value is zero.
By the way, this works same both on DirectX and OpenGL.

1 comment:

  1. It would still be beneficial to know how to tell the GPU to use only the second highes LOD. For instance when you are testing different texture sizes trying to find which one suits you best.
